5000kg载重 |
550/685mm全宽度 |
1150/1220mm叉子长度 |
| 技术参数Specifications | ||
| 型号Model | CBY-5T | |
| 载重Load Capacity | kg | 5000 |
| 最低高度Lowest Fork Height | mm | 85 |
| 最大提升高度Maximum Fork Height (H2) | mm | 200 |
| 全宽度(Outside Fork Spread(B) | mm | 550/685 |
| 叉子长度Length of the Fork(L2) | mm | 1150/1220/1500/1800/2000 |
| 叉子宽度Width of the Fork(B1) | mm | 160x50 |
| 前轮直径Dia.Of the Front Wheel | mm | 双double Φ80x70 |
| 后轮直径Dia.Of the Steering Wheel | mm | Φ180x50 |
| 轮子材料Material Of the Wheel | Nylon | |
| 手柄高度(mm)Height of handle from the ground(H) | mm | 1250 |
| 自重Net Weight | kg |
136~175 |
